Electronic Hotel Lock-Visual RFID Aluminium

Descriptions:

  • Be-Tech VISUAL RFID Door Lock series is the latest electronic locks that use simple, fashionable and comfortable design.
  • Be-Tech VISUAL RFID Door Lock series is especially designed for the modem and fashionable hotels with the desire of make sure the lock perfectly blends into fashionable hotels’ environment.
  • “The sparkling bright spot, not just the looks”. With the combination of Be-Tech VISUAL Aluminium RFID series and Matt black spray coating finish, it allows architects and designers to maximize a hotel’s fashion sense and to enhance the users’ experience to a new level.

Main Features of the Product

  • The RFID Door Lock is specially designed as a stand alone electronic lock with RFID technology.

  • The blue color mutation LED indicator on the outside escutcheon looks like saying "Hello" to hotel guests.

  • Operates with a completely sealed contactless module.

  • High security stainless steel mortise lockcase available in ANSI, AUS and EURO versions.

  • Mortise approved by CE and ANSI/BHMA.

  • Comfortable touch aluminium handle with high strength central spindle.

  • 3-point stainless steel latch construction with antifriction mechanism.

  • Mortise equipped 20mm throw high strength deadbolt.

  • Panic release function: The deadbolt and latch can be automatically retracted by inside handle for easy regress in emergency.

  • ADA compliant (guest with physical disabilities).

  • Future proof re-programmable FLASH RAM lock memory.

  • The RFID Door Lock is powered by 4AA batteries that provide up to 1 year normal life time.

  • 400 event audit trail.

  • Compatible with BIS HOTEL software platform.

  • High security mechanical override cylinder available.

Technical Data

Power 4x 1.5V AA alkaline batteries
Battery Location Inside of the front lock
Inside of the front lock Material
Handles: SUS 304Stainless Steel Lock body: Aluminium Alloy
Metal Finishes Matte Black
Emergency Opening Options Emergency Opening with Mechanical
cylinder
Locking Mechanism Electro-mechanical locking mechanism
Door Thickness 35-80mm (only for EURO mortise)
System Software Compatibility BIS Hotel
Storage Temperature Workable -20°C~80°C: non-condensing
environment
Tested Operating Temperature Tested from -25°C~70°C
Supported RFID Standard ISO 14443 A (MIFARE Classic)
